CAEN RFID Circular Polarized Antenna 8.5dBc – ETSI

CAEN RFID Circular Polarized Antenna 8.5dBc – ETSI
Minimum 1pcs
-
+
Request unit price

We react on your
request in 24 hours

Shipping
worldwide

Printing &
encoding

  • Frequency: 860-960 MHz
  • Key application : Waste management, Asset Tracking,
Have questions about this product? ☎  +358 10 20 80 750

CAEN RFID Circular Polarized Antenna 8.5dBc – ETSI

Applications: RAIN RFID portal for logistic, Industrial automation reading points, RAIN RFID tunnels, Access control reading points

This antenna is designed for RAIN RFID long range application like portals, vehicles identification, access control or waste management.

Thanks to the circular polarization, the tag read range is independent from the relative tag – antenna orientation.

The enclosure is IP65 rated for outdoor installation.

Features

  • Designed for RAIN RFID long range application
  • Frequency Range 865 ÷ 868 MHz
  • Gain 8.5 dBc
  • Right Hand Circularly Polarized (RHCP)

Product datasheet of CAEN RFID Circular Polarized Antenna 8.5dBc – ETSI

SPECIFICATIONS
    PHYSICAL
  • Product:WANTENNAX019
  • Dimensions:270 x 270 x 75 mm / 10.63 x 10.63 x 2.95 in
  • Weight:1.2 kg
    TECHNICAL
  • Frequency:860-960 MHz
  • Operating frequency:865.6-867.6 MHz (ETSI EN 302 208 v. 3.1.1)
  • RF power:2W ERP (ETSI EN 302 208 v3.1.1) - Max. 5W
  • Polarization:Right Hand Circularly Polarized (RHCP)
    ENVIRONMENT
  • IP Protection:IP65
  • Operating temperature:-30°C to 60°C / -22°F to 140°F
